Maxxi Floors Vanguard Ash Luxury Vinyl Flooring
Maxxi Floors Vanguard Ash Luxury Vinyl Flooring - Image 2

Maxxi Floors · Vanguard

Maxxi Floors Vanguard Ash Luxury Vinyl Flooring

Contact us for pricing

SKU MAXXI-WEB-4294

Calculate Flooring

22.7 sq. ft. per box · product specification

Material estimate only. Installation, delivery, and taxes are not included.

Contact us to confirm pricing and ordering.

Request Estimate

Need installation? Include it in your estimate request.

Product specifications

manufacturer

collection

Color

Ash
Color / Tone

Grey
Flooring Type

Luxury Vinyl
Manufacturer product page

https://www.maxxifloors.com/products/vinyl/vanguard-collection/ash-2/
Selling unit

Square foot
width

length

WEAR LAYER

thickness

Core Thickness

5.5 mm
Attached Underlayment

1.5 mm IXPE
Pad Material

IXPE
Cartons per Pallet

52
coverage-box

Sq. Ft. per Pallet

1180.40
Core Material

SPC
Water Protection

Waterproof
Edge Profile

V-Groove Painted Bevel
Finish

Ultra Matte
Length Tolerance

ISO24337 / ASTM F2055; 1524 +/-0.5 mm
Width Tolerance

ISO24337 / ASTM F2055; 230 +/-0.2 mm
Thickness Tolerance

ISO24337 / ASTM F387; 7.0 +/-0.2 mm
Flatness

ISO24337; Length concave <=0.15%; convex <=0.2%; Width concave <=0.15%; convex <=0.2%
Squareness

ASTM F2055; <=0.25 mm
Residual Indentation

ASTM F1914; <=0.18 mm
Surface Integrity

ASTM F1914; No puncture through wear layer
Static Loading

ASTM F970 / F387; Commercial <=0.13 mm; Residential N/A
Micro Scratch Resistance

EN16094; B1
Scratch Resistance

ISO1518:2019 Stylus C; No surface damage at weights >=20 N
Castor Chair

EN425; Minimum 9000 cycles
Dimensional Stability

ISO23999 / ASTM F2199; <=0.1% (80 C; 6 hours)
Curl

ISO23999 / ASTM F2199; +/-2 mm (80 C; 6 hours)
IIC

ASTM E492-09:2016; 62
STC

ASTM E90-09; 63
Heat Resistance

ASTM F1514; Delta E<=8
Light Resistance

ASTM F1515; Delta E<=8
Fire Rating

EN13501-1; Class Bfl s1
Certifications

,

VOC Emission

BS ISO16000 / ASTM D5116; Certified FloorScore and GREENGUARD Gold
Phthalate Content

CPSC-CH-C1001-09.3; Not Detectable
Vinyl Chloride Monomer

ASTM D4443-95(2002); Not Detectable
Heavy Metals

ASTM F963; Pass
Underfloor Heating

Suitable; Maximum 27 C
Chemical Resistance

ASTM F925; Pass
Surface Gloss

ASTM D523-14(2018); 2.0-3.5 GU
Slip Resistance

DIN51130:2014; R9; EN13893; Class DS
Manufacturer specification sheet

https://www.maxxifloors.com/wp-content/uploads/2025/02/Vanguard-Collection-Specification-Sheet-3.pdf

About this floor

Maxxi Floors Vanguard Ash is part of the Vanguard collection from Maxxi Floors.

  • Width: 9 Inches
  • Length: 60 Inches
  • Thickness: 7 mm
  • WEAR LAYER: 20 mil
  • Core Material: SPC
  • Water Protection: Waterproof
  • Attached Underlayment: 1.5 mm IXPE
  • Coverage per carton: 22.70

Contact JV Wood Floors for pricing and a flooring estimate. Verified specifications are listed in Product Details.

See the official Maxxi product information.
